EGMC1520
Super heavy gantry. 18,000 kg. Large & heavy parts, effortlessly.
Super heavy gantry machining center for the largest, most demanding parts — aircraft components, ship molds, power plant parts. 2,000×1,600 mm axis travel, 15–18.5 kW spindle, 18,000 kg weight.
Key Features & Benefits
Wide Motion Range (3–4 Axes)
Manages larger, complex components without repeated repositioning.
Premium Japanese/Taiwanese Components
FANUC control, HIWIN linear guides and spindle for dependable functionality.
Okada Inclined 90° Milling Head
Precision machining of sloped surfaces and challenging geometries.
Disc-Style Tool Magazine
24 tools with swift 2.5-second automatic exchanges.
Heavy-Duty Worktable
Exceptional steadiness under substantial loads, minimizes oscillation, extends machine life.
Technical Specifications
Full specifications for the EGMC 1520. Contact our team for custom configurations or application-specific requirements.
Download PDF| Axis Travel (X,Y,Z) | 2000×1600×800 mm |
| Spindle Hole (7:24) | BT50 |
| Operating System | FANUC 0i MF Plus |
| Dimensions (W×D×H) | 5500×3800×4300 mm |
| Table Size | 1300×2000 mm |
| Spindle Nose-Table Distance | 185–985 mm |
| Number of Axes | 3–4 |
| Spindle Motor Power | 15–18.5 kW |
| Tool Magazine Capacity | 24 tools |
| Spindle Speed | 6,000 rpm (inclined) |
Get a Quote for the EGMC 1520
Contact our sales team for the best price and unit availability. We respond within hours.
