ECNC6040MATC
Faster Production with Automatic Tool Changing
The ECNC 6040 M ATC is built for workshops and manufacturers looking to increase productivity while maintaining consistent machining quality. Its Automatic Tool Changer (ATC) reduces manual intervention by switching tools automatically during machining, helping shorten cycle times and improve workflow efficiency Equipped with a 4 kW, 40,000 RPM water-cooled spindle, AC servo motors, and premium motion components, the machine delivers reliable performance for machining aluminum, copper, graphite, engineering plastics, and other non-ferrous materials. It supports both wet and dry machining and can be configured with optional accessories to suit different production requirements
Key Features & Benefits
Mach-3 Control
User-friendly control software that simplifies machine setup and day-to-day operation
Automatic Tool Changer (ATC)
Changes tools automatically during machining to reduce downtime and improve production efficiency
4 kW Water-Cooled Spindle
High-speed spindle running up to 40,000 RPM for faster machining and cleaner surface finishes
AC Servo Motion System
400 W AC servo motors provide smooth, accurate motion and reliable performance during continuous operation
High-Quality Motion Components
Built with HIWIN linear guides and TPI ball screws for dependable accuracy and long service life
Built for Continuous Production
Designed for long operating hours with stable performance and consistent machining quality
Technical Specifications
Full specifications for the ECNC 6040 M ATC. Contact our team for custom configurations or application-specific requirements.
Download PDFCompatible Materials
Applications
- Footwear molds
- Rubber dies
- Pharmaceutical molds
- Precision drilling
- Embossing
| Dimensions (W×D×H) | 2000×1400×2000 mm |
| Table Size | 650×450 mm |
| Axis Travel (X,Y,Z) | 600×400×170 mm |
| Spindle Nose-Table Distance | 0–200 mm |
| Number of Axes | 3–4 |
| Max Tool Diameter | 8 mm |
| Spindle Type | Water-cooled GDZ/HQD |
| Spindle Power/Speed | 4 kW / 40,000 rpm |
| Table Type/Max Load | Flat bed / 100 kg |
| Control System | Mach-3 |
Get a Quote for the ECNC 6040 M ATC
Contact our sales team for the best price and unit availability. We respond within hours.
