ECNC8040CMBT40
More Capacity .. Greater Stability
The ECNC 8040 CM BT40 is designed for manufacturers who require a larger working area, greater machining stability, and reliable performance for light to medium metal machining Built with a rigid cast iron structure, a BT40 spindle, and industrial-grade motion components, it delivers the strength and consistency needed for molds, machine parts, precision components, and continuous production
Key Features & Benefits
BT40 High-Performance Spindle
Delivers the power and rigidity required for demanding metal machining applications
Cast Iron Chassis
The cast iron structure reduces vibration, helping maintain stable machining and consistent accuracy
Hard Metal Capability
Suitable for machining stainless steel, titanium, hardened steel, cast iron, aluminum, brass, and copper
Fully Enclosed Structure
Keeps chips and coolant contained inside the machine, providing a cleaner and safer machining environment
4th & 5th Axis Ready
Supports optional 4th and 5th axis configurations for machining more complex parts with greater flexibility
Premium Motion Components
Built with HIWIN linear guideways and industrial-grade motion components for reliable long-term performance
Technical Specifications
Full specifications for the ECNC 8040 CM BT40. Contact our team for custom configurations or application-specific requirements.
Download PDFApplications
- Injection mold dies
- Thermoforming dies
- Precision drilling
| Dimensions (W×D×H) | 2500×1950×2300 mm |
| Table Size | 1200×550 mm |
| Axis Travel (X,Y,Z) | 800×400×450 mm |
| Number of Axes | 3 - 5 |
| Spindle Type | BT40 |
| Spindle Power/Speed | 7.5 kW / 12,000 rpm |
| Spindle Nose-Table Distance | 125–525 mm |
| Max Tool Holder Diameter | 40 mm |
| Table Type/Max Load | T-Slot bed / 300 kg |
| Guides & Bearings | HIWIN/TPI |
Get a Quote for the ECNC 8040 CM BT40
Contact our sales team for the best price and unit availability. We respond within hours.
